set up your Monitors
Step One
You will need:
- Touchscreen Monitor
- Standard Monitor
- Touchscreen Monitor Power Supply
- Standard Monitor Power Supply Cable
- Touchscreen Monitor USB Cable
- Display Port to VGA Cable (Order Through Zones)
- HDMI Cable
Step Two
Place your new monitors where you can comfortably install the cables.
Step Three
Plug the power supply cable into the touchscreen monitor.
Step Four
Plug the touchscreen monitor’s USB cable into the touchscreen monitor.
Step Five
Plug the HDMI cable into the touchscreen monitor.
Step Six
Plug the VGA end of the Display Port to VGA cable into the Standard monitor.
Step Seven
Plug the opposite end of the touchscreen monitor’s USB cable into the Latitude dock.
Step Eight
Plug the power supply cable into the Standard monitor.
Step Nine
Plug the opposite end of the Display Port to VGA into the Display Port on the Latitude dock.
Step Ten
Plug the opposite end of the HDMI cable into the Latitude dock.
Step Eleven
Press the power buttons to turn on your monitors.
Step Twelve
To configure your monitors, navigate to the desktop.
Step Thirteen
Right-click the desktop and select Screen resolution. Set the resolution for the monitors to the maximum resolution available.
Step Fourteen
If the cursor is flowing incorrectly from screen to screen, you may need to adjust the order of the displays. Drag the monitor with the Windows Start Menu preview into the left monitor position. Click Apply to test your changes.
Step Fifteen
Click OK to save your changes once the cursor is flowing correctly from screen to screen.
Step Sixteen
Congratulations! You have installed the Touchscreen and Standard monitor.
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
<
>
Touchscreen and Standard Monitor
Estimated Installation Time
15-20 minutes
